More about the product
The Audison SB10SA1 is a great option for adding powerful bass to your car audio system. This sealed Aerpro 10″ Loaded Slimline Subwoofer Box is designed to save space, with dimensions of 341mm (H) x 485mm (W) and a tapered depth of 85mm to 135mm, making it easy to install in most vehicles. With an internal volume of 11.31 litres and a 232mm mounting cutout, it provides an ideal setup for clean, punchy bass.
The APS10D 800W Subwoofer used is designed to deliver maximum performance in a sealed enclosure with ultra-compact volumes, from 10 lt. to 12 lt. The dual voice coil features push connectors for ease of wiring and configuration. Prima subwoofer components have been developed with a primary goal: to deliver high output in tight spaces. Output is a matter of excursion; the more air the cone moves, the more output. However, reduced mounting depth traditionally has meant low excursion.
Prima subwoofers employ a special cone-dust cap-basket geometry which guarantees large excursion of the mobile group while keeping the mounting depth to a minimum. The surround and spider have been carefully designed to prevent the “rocking – -mode” phenomenon. The cooling circuit has been designed with air vents on the basket underneath the spider, eliminating the need for vents on the bottom – plate. This allows the subwoofer to be mounted close to the back wall of the enclosure, making the most of the reduced mounting depth.
Please Note: The slimline subwoofer box used is the Aerpro SB10S and is not made by Audison.
Features:
- Fits easily in most vehicles without taking up too much space, thanks to its slimline dimensions and tapered depth.
- Sealed Enclosure Enhances sound clarity and delivers tight, punchy bass for a more precise audio experience.
- Durable 12mm MDF Construction ensures long-lasting performance while minimising vibrations for better sound quality.
- Spring-Loaded Banana Socket Terminals allow quick, secure, and hassle-free wiring connections.
- Black Carpet Finish blends seamlessly with most car interiors while protecting the enclosure from scratches and wear.
- Specially designed cone, dust cap, and basket geometry ensure long linear excursion capability (11mm, One Way) keeping mounting depth to a minimum.
- Air vents on the basket underneath the spider, eliminating the need for the central pole vent allowing mounting close to rear wall of enclosure.
- Massive motor assembly, optimized with FEM (Finite Element Modelling) for perfect control under high power, high excursion conditions.
- Water-repellent pressed paper 10-inch cone, featuring a profile developed with FEM simulation and optimized with the Klippel Scan Vibrometer.
- Designed and engineered to deliver exceptional performance in a sealed enclosure, ensuring powerful bass and precise sound reproduction.
- A steel mesh grille and plastic gasket are integrated to protect the subwoofer, ensuring durability and safeguarding against damage.
Specifications:
- Type: Sealed Enclosure
- Power Handling – MAX: 800W
- Power Handling – RMS: 400W
- Impedance: 2-Ohm
- Voice Coil: Dual (4 + 4)
- Volume: 11.31 Litres
- Construction: 12mm MDF
- Carpet Colour: Black
- Terminals: Spring-Loaded Banana Sockets
- Dimensions: (H) 341mm x (W) 485mm x Top (D) 85mm x Bottom (D) 135mm
- Weight: 9.80kg
Technical details
- Brand
- Audison
- Power (RMS)
- 400WRMS
