5-Channel Car Amplifier
Amp technology has come a long way since a 5-channel amp would take up a big chunk of your trunk. JBL's Stadium 5 five-channel car amplifier can deliver 75 watts RMS to each of your front and rear speakers, plus send up to 350 watts RMS to a subwoofer — serious power from a compact chassis that fits easily into most vehicles. Or, for maximum amp output, you can power a pair of high-performance component speakers with 200 watts RMS each and a subwoofer with 350 watts RMS.
Variable high and low-pass filters optimise the amp's output to your speakers and subs, increasing the efficiency of the system. For the sub channel, a bass boost and phase switch help you get the bass sounding just the way you want it. And JBL includes a wired remote control so you can adjust the sub channel from the front seat.
This amplifier can accept low or speaker-level inputs so it'll work in almost any system, and the package includes screw-on RCA-to-bare wire adapters for the speaker-level signal. JBL has also included their electrical anti-rotational locking (E.A.R.L.) ground terminal, for a more conductive and secure ground connection for the amplifier.
What's Speaker-Level Input?
Traditionally, car amplifiers needed the head units that drove them to have RCA pre-outs to provide the sound signal. With the advancement of technology and the efforts car makers are putting into the design and integration of media centres into our cars, changing out the head unit isn't always the best, or most cost effective choice.
Speaker-level inputs allow the amplifier to integrate seamlessly to factory entertainment units to supply more power to higher spec'd after market speakers and subs.
JBL Audio Stadium 5 Specifications
The JBL Stadium 5 is a part of the premium Stadium JBL Audio range. The engineering, build quality, attention to detail and performance of these products is outstanding and on another level.
- 5-Channel Car Amplifier
- 75 watts RMS x 4 + 200 Watts RMS x 1 at 4 ohms
- 100 Watts RMS x 4 + 350 watts RMS x 1 at 2 ohms
- 200 Watts RMS x 2 Bridged at 4 ohms + 350 watts RMS x 1 at 2 ohms
- Separate Variable High- and Low-Pass Filters (32-320 Hz, 12 dB/octave) on front and rear channels
- Low-Pass Filter on Subwoofer Channel (32-320 Hz, 12 dB/octave)
- Bass Boost on Subwoofer Channel (0-9 dB at 70 Hz)
- Phase Switch on Subwoofer Channel (0, 180 degrees)
- Wired Remote Bass Level Controller Included
- Six 30A ATO Fuses (3 Installed)
- 6 Bare Wire-to-RCA Adapters
- EARL Ground Terminal (for 1/0-gauge wire)
- 3 Flat-Head Screws (Length 1/2″)
- Heat Shrink Tube (Length 1-3/16″)
- 4 Mounting Screws (Length 2-3/16″)
- 1/0-Gauge Power/Ground Wire Adapter
- Remote Bass Controller
- 16.5′ Remote Cable (RJ25 Plugs on Both Ends)
- Owner’s Manual
Technical details
- Brand
- JBL Audio
- Warranty
- 12-months
